Model: FX OR-60 (72V60A) / FX OR-48 (72V48A)

Battery: 72V60AH Lithium Fero Phosphate Battery / 72V48AH Lithium NCM Battery, Liquid Cooled

Available Colours: Matte Black, Red, All Black

Controller: Sine Wave Vector Controller

Overall Size: 2080x800x1160mm

Frame: Patented Aluminum-Magnesium Alloy One-Piece Frame (Zero Welding)

Wheel Base: 1300mm

F/R Type: 80/100-21/ 100/90-18

Battery Capacity: 4320Wh / 3456Wh

Rated Power: 5000W

Max Power: 12000W

Max Range: 180KM (@30KM/H) / 150KM(30KM/H)

Max Speed: 100KM/H

Rear Torque: 380N.m

Gradeability: 40% Slope

Front Fork Stroke: 230mm

Ground Clearance: 340mm

Seat Height: 910mm

Vehicle Weight: 97.5KG / 97KG

Max Load: 120KG

Wading Depth: > 7500mm

Charging Time: 4H / 3H

Battery Auxiliary Heat: -40°C Normal Charging

Operation Temperature: -40°C - 50°C

Carton Packing Size: 1800*420*880mm

Loading (20GP/40HQ): 32/102
